Vim li cas thiaj xaiv DIMI Stainless Steel Drop Wire Clamp?
Superior Corrosion tiv thaiv
304 stainless hlau kev tsim kho tiv thaiv ntug dej hiav txwv ntsev, tshuaj lom neeg, thiab huab cua huab cua
Kev tuav ruaj khov siab kawg
Rated rau 555 lbs tensile load ib Telcordia GR-3174 specification, tiv thaiv cable slippage txawm nyob rau hauv kev nyuaj siab heev
Kev siv ntau yam
Txhawb 1-2 khub xov tooj poob hlau, fiber ntau optic cables, thiab CATV tub txib cables hauv kev teeb tsa dav hlau
Ib -stop Solution
Engineered rau 20+ xyoo kev pab cuam lub neej nyob rau hauv ib puag ncig sab nraum zoov uas yuav tsum tau saib xyuas tsawg kawg nkaus
Technical Specifications
| Parameter | Specification |
|---|---|
| Khoom siv | |
| Lub cev / Plhaub | 304 Stainless hlau |
| Xim | 304 Stainless hlau (Serrated los yog Neoprene) |
| Daim Hlau | 430 Stainless hlau |
| Npuag | 304 Stainless hlau |
| Kev ntsuas ntsuas | |
| Maximum Tensile Load | 555 lbs (252 kg) ib Telcordia GR-3174 |
| Ua haujlwm kub | -40℃F txog +140℃F (-40℃rau +60 degree) |
| UV Resistance | Zoo heev (20+ xyoo tawm sab nraum zoov) |
| Corrosion Resistance | Superior (ASTM B117 ntsev tsuag tshuaj ntsuam) |
| Cable Compatibility | |
| Hom hlau | 1-2 khub xov tooj poob hlau, fiber ntau optic cable, CATV tub txib |
| Cable Diameter Range | 0.160" - 0.330" (4.0mm - 8.4mm) |
| Pom zoo Span Length | Txog li 150 feet ntawm kev txhawb nqa |
| Lub cev Dimensions | |
| Zuag qhia tag nrho ntev | 3.5 nti (89mm) |
| Daim Hlau Qhov siab | 4.0 nti (102mm) |
| Nyhav ib Unit | 0.18 lbs (82g) |
| Standards & Certifications | |
| Ua raws | Telcordia GR-3174, NESC Qib "N", ISO 9001 |
| Cov qauv xeem | ASTM B117 (Salt Spray), ASTM D4329 (UV Weathering) |
Khoom nta
Superior Material Engineering
304 Stainless Hlau Kev Tsim Kho - Lub cev, shim, thiab cov khoom sib txuas yog tsim los ntawm hwm- qib 304 stainless hlau, muab tshwj xeeb tiv thaiv xeb, corrosion, thiab ib puag ncig degradation.
Qhov kev xaiv cov khoom no ua kom ntseeg tau tias kev ua tau zoo hauv cov ntug dej hiav txwv hauv 5 mais ntawm ntug dej hiav txwv, ze rau cov roj refineries, tshuaj nroj tsuag, steel mills, thiab lwm yam corrosive industrial puag ncig.
Advanced Grip Technology
Serrated Shim Design - Cov khoom tshwj xeeb uas tsim los yog neoprene shim ua rau muaj zog tuav ntawm cov xaim xaim yam tsis muaj kev puas tsuaj rau cable rwb thaiv tsev.
Qhov kev tsim kho tshiab no faib cov siab sib npaug thoob plaws hauv cov kab hluav taws xob, tiv thaiv kev puas tsuaj rau tus neeg xyuas thaum tuav ruaj ntseg tuav hauv qhov nro loads txog 555 lbs.
Robust Mechanical Design
430 Stainless Steel Bail Wire - Cov xaim sib xyaw ua ke yog tsim los ntawm siab - lub zog 430 stainless hlau, muab lub zog tensile zoo dua thiab yooj yim rau kev txuas rau span clamps, tsav hooks, tsev hooks, thiab ntau yam khoom siv hauv huab cua.
Txoj kev tsim cov xaim hluav taws xob tso cai rau cov cuab yeej - kev teeb tsa pub dawb ntawm feem ntau cov ntsiab lus txuas.
Huab cua-Resistant Performance
Txhua yam - Huab Cua Muaj Peev Xwm - Kev tsim kho kom tiv taus qhov kub thiab txias li ntawm -40℃F txog +140℃F (-40℃txog +60} degree), UV hluav taws xob raug, muaj av noo, thiab cov khoom sab nraum zoov tsis tu ncua.
Lub stainless hlau poob hlau clamp tuav lub zog clamping zoo ib yam los ntawm thermal cycling thiab huab cua hloov raws caij nyoog.
Installation efficiency
Quick-Mount Design - Lub clamp nta ib qho yooj yim peb -daim siv (plhaub, shim, thiab wedge nrog bail wire) uas ua rau kev teeb tsa sai sai yam tsis muaj cov cuab yeej tshwj xeeb.
Cov neeg tsim khoom tuaj yeem ruaj ntseg aerial poob cables hauv feeb, txo cov nqi zog thiab cov sijhawm ua haujlwm.
Ua raws li kev nyab xeeb
Kev lag luam Standard Certification - Tsim nyob rau hauv raws li Telcordia GR-3174 specifications thiab NESC (National Electrical Safety Code) yuav tsum tau rau aerial drop hardware.
Haum rau Qib "N" muab kev pabcuam thiab kev sib txuas lus cable txuas.
Daim ntawv thov Scenario
Coastal Telecommunication Networks
Stainless hlau poob hlau clamps zoo nyob rau hauv marine ib puag ncig qhov twg ntsev tsuag, high humidity, thiab corrosive hiav txwv cua sai degrade aluminium hardware.
Pom zoo rau:
- Puam resort broadband installations
- Coastal fiber ntau-rau--lub tsev (FTTH) xa tawm
- Marina thiab waterfront kev sib txuas lus systems
- Island thiab offshore platform kev sib txuas
Industrial Facility Networks
Cov nroj tsuag tshuaj, refineries, steel mills, thiab cov chaw tsim khoom yuav tsum muaj corrosion{0}}resistant aerial drop hardware that withstands aggressive chemical atmospheres.
Pom zoo rau:
- Petrochemical refinery kev sib txuas lus network
- Steel zeb SCADA thiab tswj tshuab
- Chemical processing cog fiber qaum
- Food processing facility automation networks
Telecommunications Provider Infrastructure
Cov chaw muab kev pabcuam siv cov kev sib txuas saum huab cua rau cov neeg nyob hauv tsev thiab cov neeg ua lag luam tau txais txiaj ntsig los ntawm kev cia siab ntev -.
Pom zoo rau:
- Kawg - mais fiber ntau poob kev teeb tsa rau cov neeg siv khoom thaj chaw
- Xov tooj tuam txhab aerial service poob
- Cable TV muab kev pabcuam coaxial tub txib cable txhawb nqa
- Tsau wireless ISP aerial fiber faib
High -Tsub Ib puag ncig
Kev teeb tsa raug rau qhov kub siab ambient kub lossis radiant tshav kub los ntawm cov khoom nyob ze.
Pom zoo rau:
- Fais fab substation kev sib txuas lus txuas (ze transformers)
- Industrial chaw perimeter kev ruaj ntseg networks
- Suab puam cheeb tsam telecommunication infrastructure
- ru tsev thiab lub tsev façade-mounted aerial cable
Cov neeg siv tshuaj xyuas
Kev ntsuas tus neeg siv
Tom qab hloov mus rau DIMI Fiber stainless qauv, peb tau muaj qhov tsis muaj corrosion kiag li- cuam tshuam txog kev ua tsis tiav hauv 3+ xyoo dhau los. Qhov kev tsim kho 304 stainless yog tsim nyog rau txhua lub nyiaj hli - cov clamps tseem zoo li tshiab txawm tias tsis tu ncua ntsev tsuag.
Mike T
Network Construction Manager
Kuv tuaj yeem ua tiav tus ncej zoo ib yam-rau- lub tsev poob hauv li 15 feeb pib ua kom tiav, piv rau 25-30 feeb nrog cov ntsia hlau hom clamps. Qhov ntawd yog qhov sib txawv loj thaum koj ua 8-12 teeb tsa ib hnub. Kuv cov neeg ua haujlwm tau hais tias peb cov khoom tsim tau nce 30% txij li hloov mus rau cov clamps no. "
Jennifer M
Senior Installation Technician
DIMI Fiber's stainless hlau clamps tau ua ib qho kev ua si - hloov pauv rau peb qhov chaw. Tom qab 31 lub hlis ntawm kev raug rau peb cov mob hnyav, cov clamps qhia qhov me me ntawm qhov tsis muaj xim thiab xoom cov qauv degradation. Kuv tsuas yog qhov kev thuam me me yog tias cov hlau tsis huv tsis yog qhov zoo nkauj zoo nkauj li tshiab txhuas. "
Robert K
Facilities Maintenance Supervisor
Npaj kom muaj kev sib txawv ntawm DIMI Fiber?
Txhim kho koj qhov kev tswj hwm huab cua nrog cov kev ntseeg siab tshaj plaws stainless hlau poob hlau clamps ntawm kev ua lag luam. Rov qab los ntawm kev lag luam- ua tau zoo thiab muaj kev lav phib xaub rau 20 xyoo.
