Fiber Optic Cable LC Connector

Ntsiab nta

High-Density LC Form Factor - Compact 1.25 mm ferrule tsim ua kom muaj fiber ntau qhov chaw nres nkoj hauv racks thiab ODFs.

Singlemode & Multimode Options - Txhawb 9/125 μm thiab OM2 / OM3 / OM4 / OM5 fibers rau ntau yam kev siv.

UPC & APC End-Face Available - Xaiv UPC rau kev sib txuas dav dav lossis APC rau qis-xav, siab- rov qab- daim ntawv thov poob.

Tsawg Insertion poob, ruaj khov kev ua tau zoo - Precision zirconia ferrule xyuas kom meej fiber ntau sib dhos thiab qis optical poob.

Txhim khu kev ruaj ntseg Latch & Housing - Push-rub locking mechanism muab kev ruaj ntseg mating thiab yooj yim tuav nyob rau hauv tuab panels.

Kev Ua Raws Cai Thoob Ntiaj Teb - Tsim los ua kom tau raws li IEC / TIA / GR-326 cov cai thaum siv hauv cov rooj sib txoos tsim nyog.

100% Kuaj Ua Ntej Ua Ntej Cov Khoom Muag - Txhua qhov txuas yog kuaj xyuas cov duab geometry, qhov poob qis, thiab rov qab poob kom ntseeg tau tias sib xws.

Technical Highlights

Connector Hom: LC, simplex lossis duplex

Fiber Hom: Singlemode 9/125 μm; Multimode OM2 / OM3 / OM4 / OM5

Polish xaiv: UPC / APC (singlemode); UPC (ntau hom)

Yam Tsis Muaj Kev Txhaum Cai: Tsawg dua lossis sib npaug rau 0.2 dB (singlemode), Tsawg dua lossis sib npaug rau 0.25 dB (multimode)

Insertion poob siab tshaj plaws: Tsawg dua lossis sib npaug rau 0.3 dB

Rov qab poob: Ntau dua lossis sib npaug rau 50 dB (LC UPC), Ntau dua lossis sib npaug rau 60 dB (LC APC)

Ferrule Khoom: Zirconia ceramic, 1.25 mm

Durability: Ntau dua lossis sib npaug rau 500 mating cycles

Kev khiav hauj lwm kub: −40℃rau +75℃(nyob ntawm kev siv cable)

Daim ntawv thov

Central chaw ua hauj lwm thiab nkag mus rau network faib thav duab

FTTH / FTTx termination thawv thiab phab ntsa qhov hluav taws xob

Data center thaj vaj huam sib luag, cassettes, thiab MPO-LC breakout harnesses

Enterprise LAN, lub tsev kawm ntawv qaum tsev, thiab lub tsev riser cabling

CATV, ISP, thiab metro optical networks

Kuaj jumpers, pigtails, thiab kuaj cov hlua khi

Compatibility & Qauv

Tau tshaj tus qauv LC adapters, LC couplers, thiab LC -raws li transceivers (SFP / SFP + / SFP28, thiab lwm yam)

Tsim kom tau raws li IEC 61754-20 (LC connector tsev neeg) thiab TIA / EIA cov qauv thaum siv hauv cov rooj sib txoos tsim nyog

Txhawb ITU-T G.652D / G.657A singlemode fibers thiab OM-series multimode fibers

RoHS thiab REACH cov ntaub ntawv ua raws

Ordering Information
DIMI fiber ntau optic cable LC connectors muaj nyob rau hauv simplex los yog duplex versions, rau singlemode los yog multimode fibers, nrog UPC los yog APC polish. Cov khau raj sib txawv (0.9 mm / 2.0 mm / 3.0 mm), xim vaj tse, thiab logo luam ntawv tuaj yeem kho. Ua ntej- txiav LC thaj qaum, pigtails, thiab cov hlua khi kuj tuaj yeem muab tau raws li koj qhov project thiab vaj huam sib luag layout yuav tsum tau.

FAQ

Q1: Dab tsi yog qhov zoo ntawm LC connector piv nrog SC connector?
A1: LC connectors siv ib tug me me 1.25 hli ferrule thiab compact latch tsim, tso cai ntau dua qhov chaw nres nkoj ceev ntawm thaj panels thiab ODFs tshaj SC connectors. Qhov no pab txuag qhov chaw khib hauv cov chaw khaws ntaub ntawv thiab chav sib tham.

Q2: Thaum twg kuv yuav tsum xaiv LC UPC vs LC APC?
A2: LC UPC raug pom zoo rau feem ntau tus qauv singlemode thiab multimode cov ntaub ntawv txuas. LC APC yog nyiam nyob rau hauv cov ntawv thov uas muaj kev nkag siab zoo rau kev xav rov qab, xws li FTTx, RF hla fiber ntau, lossis ntev -haul singlemode txuas.

Q3: DIMI puas tuaj yeem muab LC connectors ua tiav thaj cords thiab pigtails?
A3: Yog. DIMI tuaj yeem xa ua tiav LC patch cords thiab pigtails nrog qhov ntev customized, hom fiber ntau, cov khoom siv lub tsho, daim ntawv lo, thiab ntim kom phim koj ODF thiab cov ntaub ntawv xa tawm.
